DFROBOT DFR0063

Expansion Board, I2C 16x2 Arduino LCD Display Module, Arduino/Genuino UNO/Leonardo Boards

I2C 16x2 Arduino LCD Display Module

Technical Documents (1)

Technical Data Sheet EN

Product Overview

16x2 LCD display screen with I2C interface is able to display 16x2 characters on 2 lines, white characters on blue background. With limited pin resources, your project will quickly run out of resources using normal LCDs. With this I2C interface LCD module, you only need 2 lines (I2C)to display the information. If you already have I2C devices in your project, this LCD module actually cost no more resources at all. The address can be set from 0x20-0x27. Fantastic for Arduino or gadgeteer based projects.

Compatible with Arduino/Genuino UNO, Leonardo, Mega, 101 (Intel Curie), Micro, Nano, Mini

I2C Address:0x20-0x27(0x20 default)

Back lit (Blue with white char colour)

Supply voltage: 5V

Interface:I2C/TWI x1, Gadgeteer interface x2

Adjustable contrast

Size: 80x36x20mmz(3.1x1.4x0.7in)
