Digital Display Time Delay Relay Timer Cycling Module DC 48V + DC 24V

Description:

Composed of intelligent DC voltmeter and DC relay control module,to realize accurate measurement of DC .

Set the upper and lower limits of the , various delays, timing, and timing loops or combination of multiple modes,which realize simple and flexible implementation of multiple system controls.

Product design in strict accordance with national standards and electrical rules.

Three high-brightness LED digital tube display; Card slot installation.

Widely used in battery and discharge control, automotive battery control, electric vehicle power supply control, DC motor control, photovoltaic power supply system and over undervoltage protection.

Specification:

Material: Electronic Components

Overall Size: 79x43x27mm/3.11x1.69x1.06inch

Hole Size: 71.3x39.1mm/2.81x1.54inch

Working : DC 20-30V (24V Relay Module); DC 40-60V (48V Relay Module)

Timing Range: 0-99.9s,0-999s,0-999min (Optional)

Standby Current: 15mA/12V

Relay: 10mA/12V (Disconnected); 45mA/12V ( )

Working Temperature: -40~85℃

Size Chart:

Function Description:

F1: Automatic and discharge and hysteresis control

F2: overrun mode (overvoltage and undervoltage protection)

F3: Battery automatic discharge control timing

F4: Timing (delay) control

F5: Manual control

long presses and short presses.

Long Presses: Press the button for about 3s to release.

Short Presses: Press the button for 1s to release.

2.SET: Setting button. : Operation button.

Package Includes:

1 Piece DC 24V Digital Relay Timer Module

1 Piece DC 48V Digital Relay Timer Module
