Cooling/Power/Form Factor

• Max Power: 235W
• Bus Interface: PCIe® x16
• Slots: Two
• Form Factor: Full height/ Full length
• Cooling: Passive heat sink

Memory

• Size/Type: 16GB GDDR5
• Interface: 512-bit
• Bandwidth: up to 320 GB/s

Compute Performance

• Half rate double precision
• 5.07 TFLOPS peak single-precision and 2.53 TFLOPS peak double-precision floating-point performance
• Error correcting code (ECC) memory support (external only)

Display Outputs

• Headless display support
• No physical display outputs

API and OS Support

• API Support: DirectX® 11.1, OpenGL 4.3 and OpenCL™ 1.2; OpenCL 1.2 conformance expected
• OS Support: Microsoft® Windows 8.1, Windows® 7, Windows Server® 2012 R2, Windows Server® 2008 R2 SP1 and Linux® (32- or 64-bit)

Enabled AMD Technologies

• AMD STREAM technology2
• AMD PowerTune technology4

System Requirements

• 20 CFM airflow cooling at 45° C maximum inlet temperature
• Available PCI Express® x16 (dual slot), 3.0 for optimal performance
• Power supply plus one 2x4 (8-pin) and one 2x3 (6-pin) AUX power connectors
• 2GB system memory
• Supported OS; see API and OS Support above
• Internet connection for driver installation
